LED Tubes T8 , LED T8 Lamps
Home / Products / LED Energy Saving / LED Tubes T8 , LED T8 Lamps
Model No : LED-205S
Functions & Characteristics:
LED T8 Lamps Manufacturer and Supplier
- 3014 LED, the light does not have flicker, harmless to the human body, do not injure eyes and Operation life is about 50000 hours.
- The material of side is Aluminum Alloy and high light transmittance acrylics.
- The lamp is isolated LED electric current designed definitely, high efficiency, long life.
- Can match traditional T8 lamp holder.
- Good Color Rendering Index (CRI).
- Application places: Hallway, door gate, corridor, stairs, garage, balcony and basement & etc.
Specification:
| Model No. | LED-205S | |||
|---|---|---|---|---|
| Model name | T8 LED tube with sensor luminance | T8 LED tube with sensor luminance | T8 LED tube with sensor luminance | T8 LED tube with sensor luminance |
| 100% | 25% | 100% | 25% | |
| Dimension | L580mm | L1200mm | ||
| Power Supply | AC85-265V | |||
| Normal Rated Power | 9W | 9W | 18W | 18W |
| Luminous Flux | >800LM | >1600LM | ||
| Color temperature | 6000K-6500K | |||
| PF | PF>0.93 | |||
| Working temperature | -10°C ~+45°C | |||
| Total Luminous Efficiency | >75LM/W | |||
| Working Frequency | 50/60HZ | |||
| Light angle | 140 degree | |||
| Sensing distance | 8m (at 25°C ) | 8m (at 25°C ) | 8m (at 25°C ) | 8m (at 25°C ) |
| Sensing angle | R&L:<120°, UP&DOWN:<90° |
|||
| Delay time | According to customer requirements into 30 seconds, 60 seconds, 120 seconds, 180 seconds | |||
| Type | Night and all day | Micro-light type | Night and all day | Micro-light type |
