LED-203 12W LED Downlight with Sensor
Home / Products / LED Sensor / LED-203 12W LED Downlight with Sensor
Model No : LED-203
Functions & Characteristics:
- Taiwan LED, beam angle is 120°, a life span is 30,000 hours.
- LED sensor light energy saving, long life, high performance, life expectancy is 10 times more than traditional fluorescent lamps.
- With built- in sensor PIR-615-C & D.
- Special circuit design which can resist spark, surge and noise.
- Time, day& night and distance can be adjusted
- Application place: Indoor place, show cupboard, walks, the restaurant, living room, department store, boutique & etc.
Specification:
LED Lamp Sensor
| Model No. | LED-203 12W |
|---|---|
| Power Supply | AC100~240V 50/60Hz |
| Color Temperature | CW：6000K，WW：3000K |
| Luminous Flux | CW：820LM，WW：900LM |
| CRI | 80 |
| Operating Temperature | -10°~ +40° |
| Sensing Angle | R&L：130°，Up& Down：90°(at 25°C) |
| Sensing Distance | 8m (at 25°C ) |
| Function control | Day& night adjustable. |
| Delay time | 6 sec.-600 sec. |
| Warm-up Procedure | Install at daytime: the lamp will light for 6 seconds after energized. Install at nighttime: the lamp will light for about 15 seconds then automatically shut off after energized. (under” Moon “ status) |
| External Diameter | Φ180 mm , H：40 mm |
| Fitting hole | Φ 150 mm |
| Wiring | 2 IN |
